The DES-108 is an 8-Port, Fast Ethernet switch for the SMB and Enterprise needing a flexible and easy to install unmanaged solution. The DES-108 is housed in a metal chassis providing a durable alternative to plastic. With no fan to create noise, the DES-108 runs discretely in the background allowing for deployment into locations where quiet operation is a necessity. The DES-108 is compact in size and wall mountable, ensuring hassle-free installation in virtually any location. With a non-blocking / wire-speed architecture, support for 802.3x flow control, auto-detection for speed, duplex, and cable type, the DES-108 is the perfect blend of quality, simplicity, and affordability.
MAC Address Table Size - 1K
Switch Fabric - 1.6 Gbps Forwarding Capacity
Transmission Method - Store-and-forward
Diagnostic LEDs
- Per Unit Power
- Per Port Activity/Link
Packet Buffer Memory - On Chip 64Kbyte Buffer Memory Per Device
Forwarding Rate - 10Mbps- 14,880pps/100Mbps- 148,810pps
Address Aging Timer - Automatic Update
Max Power Consumption - 3.35 Watts (Max)
RJ-45 - 10BASE-T, 100BASE-TX Universal UTP Cable Recognition for Straight-Through or Crossover Cables (MDI/MDI-X)
IEEE - 802.3 Ethernet, 802.3u Fast Ethernet, 802.3x Flow Control
Emissions - FCC Class B, CE Class B, VCCI Class B
Power Supply - DC 7.5V / 1A External
Safety - CSA International
Dimensions (W x H x D) - 7.5 x 4.5 x 1.25 inches (192.5 x 118.5 x 32 mm)
Warranty - 5 years
